| Product Name |
10/100M 6-port long distance standard PoE power supply switch. |
| Product Model |
KU-9006N |
| Port Description |
4 RJ45 10/100M PoE ports + 2 RJ45 10/100M network ports. |
| Network Medium |
10BASE-T: Class 3, 4, 5 unshielded twisted pair (≤100m)
100BASE-TX: Unshielded twisted pair (≤100m) with Category 5 and above |
| Bandwidth |
1.2Gbps |
| MAC Address List |
1K |
| Network Protocol |
IEEE 802.3i、IEEE 802.3u、IEEE 802.3x Flow Control、IEEE 802.3af 、IEEE802.3at |
| Other Hardware Features |
Adjustable by toggle switch, select 250 meters long distance, open/close VLAN. |
| PoE Port |
1-4 ports support IEEE802.3af/at (15.4W/30W) network power supply |
| PoE Standard |
Compliant with IEEE 802.3af/at international standard, single port maximum power supply 30W. |
| PoE Type |
Default end span method (optional mid-span method) |
| PoE Port Features |
Power per port 15.4W (IEEE802.3af) / 30W (IEEE802.3at) |
| PoE Transmission Wire Core |
Default 1/2+, 3/6-pair (optional 4/5+, 7/8-pair) |
| PoE Total Power |
72W |
| Environmental Specification |
Working temperature: -20 °C ~ 55 °C
Storage Temperature: -40 ° ~ 75 °C,
Working Humidity: 10% ~ 90%, no condensation
Storage Humidity: 5% ~ 95%, no condensation
Working Height: altitude 3000 m (10,000 ft)
Storage Height: 3000 m (10,000 ft) above sea level. |
| Power Supply |
Input Power: AC100-240V, 50-60Hz,
Total Power: 72W |
